Optical
feature |
Wavelength
1310±20nm
|
Output power 4～20mW
|
| Connector type FC/APC or SC/APC |
| Return loss ≥60dB |
RF
Features |
Frequency 47～750MHz (862MHz optional)
|
| Impedance 75Ω |
| Return loss ≥16dB (47～550MHz)
≥14dB (550～862MHz) |
| Flatness ±0.75dB (47～550MHz)
±1.0dB (47～862MHz) |
| Input signal level AGC 75～85dBμV/CH
MGC 80～85dBμV/CH (set by factory) |
| Testing port level -20dB |
Gain
Control |
MGC 10dB
|
AGC stability ±1.0dB |
| Note: MGC must be chosen when the frequency channels are less of 15channels |
Link
features |
8900I |
C/CSO ≤-60dB c |
C/CTB ≤-65dB c |
Type Link Loss Budget(dB) Output Power |
|
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
15 |
|
04 |
52.4 |
51.4 |
50.4 |
|
|
|
|
|
|
4-6 mW |
06 |
|
53.0 |
52.1 |
51.1 |
49.9 |
|
|
|
|
6-8mW |
08 |
|
|
52.9 |
51.9 |
51.0 |
49.8 |
|
|
|
8-10mW |
10 |
|
|
|
63.1 |
52.0 |
51.1 |
50.0 |
|
|
10-12mW |
12 |
|
|
|
|
52.5 |
51.6 |
50.4 |
49.4 |
|
12-13mW |
13 |
|
|
|
|
52.9 |
51.8 |
51.0 |
49.9 |
|
13-16mW |
16 |
|
|
|
|
|
52.8 |
51.8 |
51.0 |
49.9 |
≥16mW |
8900II (with Predistortion ) |
C/CSO ≤-60dB c |
C/CTB ≤-65dB c |
Type Link Loss Budget(dB) Output Power |
|
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
15 |
|
|
04 |
53.8 |
52.9 |
51.8 |
50.7 |
49.6 |
|
|
|
|
|
6-8 mW |
06 |
|
54.0 |
53.0 |
52.1 |
50.9 |
49.8 |
|
|
|
|
8-10mW |
08 |
|
|
53.8 |
53.0 |
52.0 |
50.9 |
49.7 |
|
|
|
10-12mW |
10 |
|
|
|
53.3 |
52.4 |
51.3 |
50.0 |
|
|
|
12-13mW |
12 |
|
|
|
5.5 |
52.6 |
51.5 |
50.2 |
49.9 |
|
|
13-16mW |
13 |
|
|
|
|
53.1 |
52.0 |
51.0 |
19.9 |
48.8 |
|
16-20mW |
16 |
|
|
|
|
|
53.0 |
52.0 |
51.0 |
49.8 |
48.7 |
≥20mW |
Remark:1.Test condition is 59 channels PAL-D signals 2. Under Continuous Wave 3. CNR can be
improved when Divider is equipped in the Link |
Power
Features |
Volt
AC 85～265V
|
Power Normal 25w Max 35w
|
Mechanical
Performance |
Operating Temperature 0～50OC |
Stock Temperature -25～65OC
|
| Humidity 15～95% non-density |
| Weight ≤3kg |
| Dimensions 482mm×44mm×360mm (19"1U) |
